Supported Monitor Display Resolutions
251
Mode
Resolution
(dot)
Refresh
Rate
(Hz)
Comp
uter
HDMI/HDBaseT
RGB
HV
YCbCr(8bit)
RGB
(8bit)
4:2:0 4:2:2 4:4:4
WQXGA
(Reduced
Blanking)
2560 1600 60 ✓
* Only compatible when Wide is selected as the Resolution setting in the
projector's Image menu.
Unique Aspect
Compatible Mode
Mode
HDMI/HDBaseT
RGB
YCbCr
4:4:4 4:2:2 4:2:0
8 10 12 8 10 12 8 10 12 8 10 12
Unique aspect (16:6) ✓
Mode Information
Mode
Resolution
(dot)
H Sync
(KHz)
Refresh
Rate (Hz)
Dotclk
(MHz)
Scan Type
Unique aspect
(16:6)
1920 720 45.96 60 95.045 Progressive
If the image is not projected correctly, set the timing settings on your
computer to match the values in the following tables. (You may not be able to
change these settings, depending on your computer.)
Mode
Dotclk
(MHz)
H Freq
(KHz)
V Freq
(Hz)
H
active
(dot)
H
Front
Porch
(dot)
H Sync
Width
(dot)
H Back
Porch
(dot)
Unique aspect
(16:6)
95.045 45.96 60 1920 42 32 74
Mode
V
active
(Line)
V Front
Porch
(Line)
V Sync
Width
(Line)
V Back
Porch
(Line)
H Sync
Polarity
V Sync
Polarity
Scan
Type
Unique aspect
(16:6)
720 20 8 18 P N
Progres
sive
P: Positive
N: Negative
SD
Compatible Mode
Mode
Resolution
(dot)
Refresh
Rate
(Hz)
Comp
uter
HDMI/HDBaseT
RGB
HV
YCbCr(8bit)
RGB
(8bit)
4:2:0 4:2:2 4:4:4
SDTV (480i) 720 480 59.94 ✓ ✓ ✓
SDTV (576i) 720 576 50 ✓ ✓ ✓
SDTV (480p) 720 480 59.94 ✓ ✓ ✓ ✓
SDTV (576p) 720 576 50 ✓ ✓ ✓ ✓
HD
Compatible Mode
