Epson RC620 CU - Page 81

Setup & Operation 12. Option Slots
RC620 Rev.8 65
Protected Expansion I/O Board
Typical Output Circuit Application 2
10 Output No.64
11 Output No.65
12 Output No.66
13 Output No.67
14 Output No.68
15 Output No.69
27 Output No.70
28 Output No.71
17
Output No.64 to 71 common
Expansion I/O-1
(Same)
Omit
+DC
29 Output
No.72
30 Output No.73
33 Output No.72 to 79 common
Load
GND
L
L
(Same)
(Same)
(Same)
(Same)
(Same)
(Same)
(Same)
(Same)
