6.6 Switching Power Supply
6.6.1 Switching Power Supply (15W)
Switching
Power Supply
(
15W)
Removal
(1)
Turn OFF the Controller and unplug the power connector.
(2)
Remove 10 screws and the
top panel.
(3)
Remove the Cable No. (4), (10)
connected with Switching
Power
S
upply (15W).
Refer to Maintenance:
3.2 Diagram of Cable Connections.
(4)
Remove
4 screws securing the
Switching
Power Supply and remove
the
Power Supply.
