Maintenance 3. Controller Structure
RC620 Rev.8 127
3. Controller Structure
3.1 Location of Parts
Top panel
Left side panel
Front panel
Right side panel
Bottom panel
Back panel
Front
Back
3.2 Diagram of Cable Connections
For the connections of controller inner cables, refer to the following diagram.
The diagram is a simplified development view inside the Controller.
The numbers indicated such as (1), (2), (3) correspond to the following cable list.
