Setup & Operation 12. Option Slots
RC620 Rev.8 67
Connector 2 Pin Assignments
Pin
No.
Signal Name
Pin
No.
Signal Name
Pin
No.
Signal Name
1
Input common No.80 to 87
18
Input common No.88 to 95
34
NC
2
Input No.80
19
Input No.88
35
NC
3
Input No.81
20
Input No.89
36
NC
4
Input No.82
21
Input No.90
37
NC
5 Input No.83 22 Input No.91 38 NC
6 Input No.84 23 Input No.92 39 NC
7 Input No.85 24 Input No.93 40 NC
8 Input No.86 25 Input No.94 41 NC
9 Input No.87 26 Input No.95 42 NC
10 Output No.80 27 Output No.86 43 Output No.91
11
Output No.81
28
Output No.87
44
Output No.92
12 Output No.82 29 Output No.88 45 Output No.93
13 Output No.83 30 Output No.89 46 Output No.94
14
Output No.84
31
Output No.90
47
Output No.95
15
Output No.85
32
NC
48
NC
16
NC
33
Output common No.88 to 95
49
NC
17
Output common No.80 to 87
50
NC
Connector Standard
I/O Connector (Controller side)
D-sub 50 male pin
Mounting style #4 - 40
* The I/O connector, I/O connector cable, terminal block, and I/O connector kit are offered as options.
12.3 Fieldbus I/O Board
The Fieldbus I/O board has the following 2 types.
- Fieldbus I/O master board
- Fieldbus I/O slave board
For the details, refer to the RC620 Controller Option Fieldbus I/O manual.
