Setup & Operation 14. Option : Teach Pendant TP1
RC620 Rev.8 83
Mount and Use
Mount the Teach Pendant with the wall bracket in the following procedures.
(1) Secure the wall bracket to the wall with three screws (positions are indicated by
dotted line in the Outer Dimension).
(2) Hang the handle of the Teach Pendant to Hook A.
(3) Hang the cable of the Teach Pendant to Hook B.
To Next Page
