Frequency zero speed: Defines the calculated values for the maximum frequency fM and fm
(reduced by the hysteresis entered). If the value displayed is GREEN, the calculated frequency is
in the correct range. If the value displayed is RED, the parameters given in the following formula
must be changed.
1. Rotary axis, rotary sensor. The calculated frequency is:
v][pulses/resolutionRe
60
[rev/min]rpm
[Hz]f 
2. Linear axis, rotary sensor. The calculated frequency is:
v][pulses/reRe
[mm/rev]*60
1000*[m/min]
[Hz] solution
pitch
speed
f 
3. Linear axis, linear sensor. The calculated frequency is:
[µm/pulse]solutionRe
1000*[mm/s]speed
[Hz]f 
4. Hysteresis. Only to be changed if: fM = green; fm = red
KEY:
f = Frequency
Rpm = Rotary speed
Resolution = Resolution
Speed = Linear speed
Pitch = Pitch
