AC-FO4 (Figure 15)
SIGNIFICANCE
LED
RUN
IN FAIL
EXT FAIL
SEL
OSSD1/4
CLEAR1/4
STATUS1/4
GREEN
RED
RED
ORANGE
RED/GREEN
YELLOW
YELLOW
Switch on – initial CHECK
ON
ON
ON
ON
Red
ON
ON
Table 28 – Start indication
SIGNIFICANCE
LED
RUN
IN FAIL
EXT FAIL
SEL
OSSD1/4
CLEAR1/4
STATUS1/4
GREEN
RED
RED
ORANGE
RED/GREEN
YELLOW
YELLOW
NORMAL
OPERATION
OFF
if the module is waiting for the first
message from the base unit
OFF
Opera-
tion OK
OFF
Opera-
tion OK
Indicates the signal
table NODE_SEL0/1
RED
if output OFF
ON
waiting for
RESTART
OUTPUT
state
FLASHING
if no INPUT or OUTPUT is requested
by the configuration
GREEN
if output ON
Flashing
NO feedback
loop
ON
if INPUT or OUTPUT is requested by
the configuration
Table 29 – Dynamic indication
Figure 15 –
AC-FO4
