Information in relation to connecting cables

Connection cross-section range: AWG 12–30, (single-conductor/multiple conductor)
(UL).

Only use copper wires (Cu) for 60/75 °C.

It is recommended to use separate power supplies for the safety module and for
other electrically powered devices (electric motors, inverters, frequency converters)
or other sources of interference.

Cables for connections with a length of more than 50 m must have a cross-section
of at least 1 mm² (AWG16).
The connections in the MSC system are listed in the table below:
Base unit MSC-CB
TERMINAL
SIGNAL
TYPE
DESCRIPTION
ACTION
1
24 VDC
-
Power supply 24 VDC
-
2
MASTER_ENABLE1
Input
Base unit enable 1
Input ("type B" as per
EN 61131-2)
3
MASTER_ENABLE2
Input
Base unit enable 2
Input ("type B" as per
EN 61131-2)
4
GND
-
Power supply 0 VDC
-
5
OSSD1_A
Output
Safety output 1
PNP active high
6
OSSD1_B
Output
PNP active high
7
RESTART_FBK1
Input
Feedback loop/restart 1
Input as per EN 61131-2
8
OUT_STATUS1
Output
Programmable digital output
PNP active high
9
OSSD2_A
Output
Safety output 2
PNP active high
10
OSSD2_B
Output
PNP active high
11
RESTART_FBK2
Input
Feedback loop/restart 2
Input as per EN 61131-2
12
OUT_STATUS2
Output
Programmable digital output
PNP active high
13
OUT_TEST1
Output
Output for short circuit detection
PNP active high
14
OUT_TEST2
Output
Output for short circuit detection
PNP active high
15
OUT_TEST3
Output
Output for short circuit detection
PNP active high
16
OUT_TEST4
Output
Output for short circuit detection
PNP active high
17
INPUT1
Input
Digital input 1
Input as per EN 61131-2
18
INPUT2
Input
Digital input 2
Input as per EN 61131-2
19
INPUT3
Input
Digital input 3
Input as per EN 61131-2
20
INPUT4
Input
Digital input 4
Input as per EN 61131-2
21
INPUT5
Input
Digital input 5
Input as per EN 61131-2
22
INPUT6
Input
Digital input 6
Input as per EN 61131-2
23
INPUT7
Input
Digital input 7
Input as per EN 61131-2
24
INPUT8
Input
Digital input 8
Input as per EN 61131-2
