FIELDBUS PROBE
Using this element the status of any point on the
diagram can be indicated on the fieldbus.
Up to 16 sensors can be used; the bit used to indi-
cate the state must be entered for each sensor.
The states are indicated on the fieldbus using two
bytes.
(You will find more detailed information in the
fieldbus manual on the CD-ROM "EUCHNER Safety
Designer".)
WARNING: The FIELDBUS OUTPUT is NOT a safety output.
