EUCHNER MSC - 7.2.5. OSSD (AH-FO4 SO8)

English
MSC-CB
PFH
d
(EN IEC 61508:2010)
6.06 E-9
Rated voltage
24 VDC  20 %
Power dissipation
3 W max.
Module enable (no./description)
2/PNP active high "type B" as per EN 61131-2
Digital INPUTS (no./description)
8/PNP active high as per EN 61131-2
INPUT FBK/RESTART (no./description)
2/EDM control system/automatic or manual operation possible
using RESTART pushbutton
Test OUTPUT (no./description)
4/For checking for short circuits, overload states
Digital OUTPUTS (no./description)
2/Programmable – PNP active high
OSSD (no./description)
2 pairs/Output signal switching devices – PNP active high
400 mA @ 24 VDC max.
SLOT for M-A1
Available
Connection to PC
USB 2.0 (Hi Speed) – cable length max.: 3 m
Connection to expansion module
Via proprietary 5-way bus MSCB from EUCHNER
FI8FO2
PFH
d
(EN IEC 61508:2010)
5.72 E-9
Rated voltage
24 VDC  20 %
Power dissipation
3 W max.
Digital INPUTS (no./description)
8/PNP active high as per EN 61131-2
Test OUTPUT (no./description)
8/For checking for short circuits, overload states
Digital OUTPUTS (no./description)
2/Programmable – PNP active high
OSSD (no./description)
2 pairs/Static safety outputs:
PNP active high - 400 mA @ 24 VDC max.
Connection to MSC-CB
Via proprietary 5-way bus MSCB from EUCHNER
