General data
Number of inputs max.
128
Number of outputs max.
16
Number of expansion modules max.
14
Number of expansion modules of the same type max.
4
Rated voltage
24 VDC  20 %/supply class II (LVLE)
Overvoltage category
II
Digital INPUTS
PNP active high (EN 61131-2)
OSSD (MSC-CB, FI8FO2, AC-FO2, AC-FO4)
PNP active high – 400 mA @ 24 VDC max. (per OSSD)
Digital OUTPUTS
PNP active high – 100mA @ 24 VDC max.
Response time (ms)
This response time is dependent on the following pa-
rameters:
1) Number of expansion modules installed
2) Number of operators
3) Number of OSSD outputs
The correct response time is calculated by the software
EUCHNER Safety Designer (see project report).
Fault reaction time (ms)
The fault reaction time corresponds to the reaction time,
except on SPM modules with an Encoder/proximity switch
interface. In this case the fault reaction time is 2 s.
Base unit
10.6–12.6
+ TInput_filter
MSC-CB
+ 1 expansion module
11.8–26.5
+ TInput_filter
MSC-CB
+ 2 expansion modules
12.8–28.7
+ TInput_filter
MSC-CB
+ 3 expansion modules
13.9–30.8
+ TInput_filter
MSC-CB
+ 4 expansion modules
15–33
+ TInput_filter
MSC-CB
+ 5 expansion modules
16–35
+ TInput_filter
MSC-CB
+ 6 expansion modules
17–37.3
+ TInput_filter
MSC-CB
+ 7 expansion modules
18.2–39.5
+ TInput_filter
MSC-CB
+ 8 expansion modules
19.3–41.7
+ TInput_filter
MSC-CB
+ 9 expansion modules
20.4–43.8
+ TInput_filter
MSC-CB
+ 10 expansion modules
21.5–46
+ TInput_filter
MSC-CB
+ 11 expansion modules
22.5–48.1
+ TInput_filter
MSC-CB
+ 12 expansion modules
23.6–50.3
+ TInput_filter
MSC-CB
+ 13 expansion modules
24.7–52.5
+ TInput_filter
MSC-CB
+ 14 expansion modules
25.8–54.6
+ TInput_filter
MSC-CB > module connection
Proprietary 5-way bus (MSCB) from EUCHNER
Connection cable cross-section
0.5–2.5 mm
2
/AWG 12–30 (single-conductor/multiple conductor)
Connection length max.
100 m
Operating temperature
-10–55 °C
Ambient temperature max.
55 °C (UL)
Storage temperature
-20–85 °C
Relative humidity
10% ÷ 95%
Max. altitude (above sea level)
2000 m above sea level

T
Input_filter
= max. filter time related to the settings on the project inputs (see section
"INPUTS").
Housing
Description
Electronics housing, 24-pin. max., with locking
Material of housing
Polyamide
Degree of protection housing
IP20
Degree of protection terminal blocks
IP2X
Mounting
Quick-release connection to rail as per EN 60715
Dimensions (H x W x D)
108 x 22.5 x 114.5
