FM4 (Figure 12)
SIGNIFICANCE
LED
RUN
IN FAIL
EXT FAIL
SEL
IN1–12
GREEN
RED
RED
ORANGE
YELLOW
Switch on – initial CHECK
ON
ON
ON
ON
ON
Table 22 – Start indication
SIGNIFICANCE
LED
RUN
IN FAIL
EXT FAIL
SEL
IN1–12
GREEN
RED
RED
ORANGE
YELLOW
NORMAL
OPERATION
OFF
if the module is waiting for the first mes-
sage from the base unit
OFF
OFF
Indicates the signal
table NODE_SEL0/1
INPUT state
FLASHING
if no INPUT or OUTPUT is requested by
the configuration
ON
erroneous external
connection detected
Only the number for the INPUT
with the erroneous connection
flashes
ON
if INPUT or OUTPUT is requested by the
configuration
Table 23 – Dynamic indication
Figure 12 –
FM4
