SOFTWARE EUCHNER SAFETY DESIGNER
Using the application software EUCHNER Safety Designer (SWSD), you can design logic
for the safety components connected to the control system and the MSC-CB expansions.
The MSC system and the related expansion modules monitor and control the safety com-
ponents connected.
EUCHNER Safety Designer is based on a graphical user interface using which the connec-
tions between the various components can be defined. It is described in the following:
Installing the software
PC HARDWARE – requirements
• RAM: 256 MB
(adequate for running Windows XP SP3 + Framework 4.0)
• Hard disk: > 500 MB free storage capacity
• USB port: 1.1, 2.0 or 3.0
• CD-ROM drive
PC SOFTWARE – requirements
- Windows XP with Service Pack 3 installed (or higher).
Microsoft Framework 4.0 (or higher) must be installed on the PC
EUCHNER Safety Designer is installed as follows:
• Insert installation CD.
• Wait until the software installation program is started by the AutoRun function.
Alternatively change to the folder D:/.
• Double-click the file SetupDesigner.exe.
After the installation is complete, a window appears in which the user is prompted to
close the installation program.
