ENCODER CONNECTIONS WITH RJ45 PLUG CONNECTOR (SPM1, SPM2)
Pin
SPMTB
SPMH
SPMS
Twisted *
1
Input
n.c.
n.c.
n.c.
2
GND
GND
GND
3
n.c.
n.c.
n.c.
Twisted *
4
A
A
A
5
/A
/A
/A
6
n.c.
n.c.
n.c.
Twisted *
7
B
B
B
8
/B
/B
/B
Table 9
* If twisted-pair cables are used.
Figure 4 – Connection examples
