EUCHNER MSC - Page 22

English
AZ-FO4
TERMINAL
SIGNAL
TYPE
DESCRIPTION
OPERATION
1
24 VDC
-
Power supply 24 VDC
-
2
NODE_SEL1
Input
Node selection
Input ("type B" as per EN 61131-2)
3
NODE_SEL2
Input
Input ("type B" as per EN 61131-2)
4
0 VDC
-
Power supply 0 VDC
-
5
REST_FBK1
Input
Feedback loop/restart 1
Input (as per EN 61131-2)
6
REST_FBK2
Input
Feedback loop/restart 2
Input (as per EN 61131-2)
7
REST_FBK3
Input
Feedback loop/restart 3
Input (as per EN 61131-2)
8
REST_FBK4
Input
Feedback loop/restart 4
Input (as per EN 61131-2)
9
A_NO1
Output
Normally open contact
channel 1
10
B_NO1
Output
11
A_NO2
Output
Normally open contact
channel 2
12
B_NO2
Output
13
A_NO3
Output
Normally open contact
channel 3
14
B_NO3
Output
15
A_NO4
Output
Normally open contact
channel 4
16
B_NO4
Output
Table 10
