RESTORE function
If the module MSC-CB is faulty, it can be replaced with a new module. As the entire config-
uration is saved on the M-A1 memory card, it is only necessary to insert this card in the
new module and switch on the MSC system, the backed up configuration will then be
loaded immediately. In this way interruptions in operation can be reduced to a minimum.

The LOAD and RESTORE functions can be deactivated using the software (see Figure 32).

The expansion modules must be assigned addresses during installation so they can
be used (see NODE_SEL).
 Each time M-A1 is used, it is to be carefully checked whether the configuration selected
is the configuration prepared for this specific system. Undertake a complete function
check on the system comprising the MSC and all devices connected to it (see
CHECKING the system).
FI8FO2
TERMINAL
SIGNAL
TYPE
DESCRIPTION
ACTION
1
24 VDC
-
Power supply 24 VDC
-
2
NODE_SEL0
Input
Node selection
Input ("type B" as per EN 61131-2)
3
NODE_SEL1
Input
Input ("type B" as per EN 61131-2)
4
GND
-
Power supply 0 VDC
-
5
OSSD1_A
Output
Safety output 1
PNP active high
6
OSSD1_B
Output
PNP active high
7
RESTART_FBK1
Input
Feedback loop/restart 1
Input as per EN 61131-2
8
OUT_STATUS1
Output
Programmable digital output
PNP active high
9
OSSD2_A
Output
Safety output 2
PNP active high
10
OSSD2_B
Output
PNP active high
11
RESTART_FBK2
Input
Feedback loop/restart 2
Input as per EN 61131-2
12
OUT_STATUS2
Output
Programmable digital output
PNP active high
13
OUT_TEST1
Output
Output for short circuit detection
PNP active high
14
OUT_TEST2
Output
Output for short circuit detection
PNP active high
15
OUT_TEST3
Output
Output for short circuit detection
PNP active high
16
OUT_TEST4
Output
Output for short circuit detection
PNP active high
17
INPUT1
Input
Digital input 1
Input as per EN 61131-2
18
INPUT2
Input
Digital input 2
Input as per EN 61131-2
19
INPUT3
Input
Digital input 3
Input as per EN 61131-2
20
INPUT4
Input
Digital input 4
Input as per EN 61131-2
21
INPUT5
Input
Digital input 5
Input as per EN 61131-2
22
INPUT6
Input
Digital input 6
Input as per EN 61131-2
23
INPUT7
Input
Digital input 7
Input as per EN 61131-2
24
INPUT8
Input
Digital input 8
Input as per EN 61131-2
Table 2
