EUCHNER MSC - Spm0;Spm1;Spm2

English
SPM0/SPM1/SPM2
State
Overspeed
Standstill
Speed
range
Safe state
Overspeed
No standstill
Out of range
Model
SPM0
SPM1
SPM2
PFH
d
5.98 E-9
-
-
PFH
d
(TTL/B)
-
7.82 E-9 (SPM1TB)
9.66 E-9 (SPM2TB)
PFH
d
(sin/cos)
-
7.94 E-9 (SPM1S)
9.89 E-9 (SPM2S)
PFH
d
(HTL24)
-
6.70 E-9 (SPM1H)
7.42 E-9 (SPM2H)
Rated voltage
24 VDC ± 20 %
Power dissipation max.
3 W
Encoder interface
-
TTL (models SPM1TB/SPM2TB)
HTL (models PM1H/SPM2H)
sin/cos (models SPM1S/SPM2S)
Encoder connections
-
RJ45
Encoder input signals electri-
cally isolated as per EN 61800-
5
Rated insulation voltage 250 V
Over voltage category II
Rated impulse withstand voltage 4.00 kV
Number of Encoders max.
-
1
2
Encoder frequency max.
-
500 kHz (HTL: 300 kHz)
Configurable Encoder limits
-
1 Hz … 450 kHz
Proximity switch type
PNP/NPN – 3/4-wire
Proximity switch connections
Plug-in terminals
Configurable
limit ranges
1 Hz … 4 kHz
Number of proximity switches
max.
2
Frequency max. proximity
switch
5 kHz
Max. number of axes
2
Frequency spacing stand-
still/overspeed
> 10 Hz
Spacing thresholds
> 5 %
Connection to MSC-CB
Via proprietary 5-way bus MSCB from EUCHNER
