EUCHNER MSC - 8.3.10. Module O8 (Figure 23)

English
FI8FO2 (Figure 20)
SIGNIFICANCE
LED
RECTIFICATION
MEASURE
RUN
IN FAIL
EXT FAIL
SEL
IN1–8
OSSD1/2
CLEAR1/2
STATUS1/2
GREEN
RED
RED
ORANGE
YELLOW
RED/GREEN
YELLOW
YELLOW
Internal fault
OFF
Flashes
2 or 3
times
OFF
Indicates the
physical ad-
dress of the
module
OFF
Red
OFF
OFF
Send module to
EUCHNER for repair
Compatibility error
OFF
Flashes
5 times
OFF
Flashes 5
times
Flashes 5 times
Flashes 5
times
Flashes 5
times
• Firmware version
not compatible with
MSC-CB. Send to
EUCHNER for firm-
ware upgrade.
OSSD output error
OFF
Flashes
4 times
OFF
OFF
Flashes 4 times
(only the LED corre-
sponding to the out-
put in the ERROR
mode)
OFF
OFF
• Check OSSD1/2
connections
• If the problem per-
sists, send FI8FO2
to EUCHNER for re-
pair.
Error during commu-
nication with base
unit
OFF
Flashes
5 times
OFF
OFF
OFF
OFF
OFF
• Restart system.
• If the problem per-
sists, send FI8FO2
to EUCHNER for re-
pair.
Error in another
expansion module or
MSC-CB
OFF
ON
OFF
OFF
OFF
OFF
OFF
• Restart system.
• Check which module
is in the ERROR
mode.
Expansion module of
the same type with
the same address de-
tected
OFF
Flashes
5 times
Flashes
5 times
OFF
OFF
OFF
OFF
• Change address of
the module (see
NODE_SEL)
Internal node
detection error
OFF
Flashes
3 times
OFF
Flashes 3
times
OFF
OFF
OFF
OFF
• Send to EUCHNER
for repair
Table 37 – Troubleshooting FI8FO2
Figure 20 –
FI8FO2
