EUCHNER MSC - Page 20

English
AC-FO2
TERMINAL
SIGNAL
TYPE
DESCRIPTION
ACTION
1
24 VDC
-
Power supply 24 VDC
-
2
NODE_SEL0
Input
Node selection
Input ("type B" as per EN 61131-2)
3
NODE_SEL1
Input
Input ("type B" as per EN 61131-2)
4
GND
-
Power supply 0 VDC
-
5
OSSD1_A
Output
Safety output 1
PNP active high
6
OSSD1_B
Output
PNP active high
7
RESTART_FBK1
Input
Feedback loop/restart 1
Input as per EN 61131-2
8
OUT_STATUS1
Output
State of the outputs 1A/1B
PNP active high
9
OSSD2_A
Output
Safety output 2
PNP active high
10
OSSD2_B
Output
PNP active high
11
RESTART_FBK2
Input
Feedback loop/restart 2
Input as per EN 61131-2
12
OUT_STATUS2
Output
State of the outputs 2A/2B
PNP active high
13
24 VDC
-
Power supply 24 VDC
24 VDC output, power supply*
14
not used
-
-
-
15
GND
-
Power supply 0 VDC
0 VDC output*
16
not used
-
-
-
Table 7
* This terminal must be connected to the power supply so that the module func-
tions correctly.
SPM0 – SPM1 – SPM2
TERMINAL
SIGNAL
TYPE
DESCRIPTION
ACTION
1
24 VDC
-
Power supply 24 VDC
-
2
NODE_SEL0
Input
Node selection
Input ("type B" as per EN 61131-2)
3
NODE_SEL1
Input
Input ("type B" as per EN 61131-2)
4
GND
-
Power supply 0 VDC
-
5
PROXI1_24V
Output
Connections for the
1st proximity switch
(see page 27)
Power supply 24 VDC to PROXI1
6
PROXI1_REF
Output
Power supply 0 VDC to PROXI1
7
PROXI1 IN1 (3 WIRES)
Input
PROXI1 NO contact
8
PROXI1 IN2 (4 WIRES)
Input
PROXI1 NC contact
9
PROXI2_24V
Output
Connections for the
2nd proximity switch
(see page 27)
Power supply 24 VDC to PROXI2
10
PROXI2_REF
Output
Power supply 0 VDC to PROXI2
11
PROXI2 IN1 (3 WIRES)
Input
PROXI2 NO contact
12
PROXI2 IN2 (4 WIRES)
Input
PROXI2 NC contact
13
not used
-
Not connected
-
14
not used
-
-
15
not used
-
-
16
not used
-
-
Table 8
