AC-FO4
TERMINAL
SIGNAL
TYPE
DESCRIPTION
ACTION
1
24 VDC
-
Power supply 24 VDC
-
2
NODE_SEL0
Input
Node selection
Input ("type B" as per EN 61131-2)
3
NODE_SEL1
Input
Input ("type B" as per EN 61131-2)
4
GND
-
Power supply 0 VDC
-
5
OSSD1_A
Output
Safety output 1
PNP active high
6
OSSD1_B
Output
PNP active high
7
RESTART_FBK1
Input
Feedback loop/restart 1
Input as per EN 61131-2
8
OUT_STATUS1
Output
Programmable digital output
PNP active high
9
OSSD2_A
Output
Safety output 2
PNP active high
10
OSSD2_B
Output
PNP active high
11
RESTART_FBK2
Input
Feedback loop/restart 2
Input as per EN 61131-2
12
OUT_STATUS2
Output
Programmable digital output
PNP active high
13
24 VDC
-
Power supply 24 VDC
24 VDC outputs,
power supply*
14
24 VDC
-
Power supply 24 VDC
-
15
GND
-
Power supply 0 VDC
0 VDC outputs*
16
GND
-
Power supply 0 VDC
-
17
OSSD4_A
Output
Safety output 4
PNP active high
18
OSSD4_B
Output
PNP active high
19
RESTART_FBK4
Input
Feedback loop/restart 4
Input as per EN 61131-2
20
OUT_STATUS4
Output
Programmable digital output
PNP active high
21
OSSD3_A
Output
Safety output 3
PNP active high
22
OSSD3_B
Output
PNP active high
23
RESTART_FBK3
Input
Feedback loop/restart 3
Input as per EN 61131-2
24
OUT_STATUS3
Output
Programmable digital output
PNP active high
Table 6
