WARNING: If Manual Reset is selected, the next Input must be used. Example: If In-
put1 and Input2 are used for the function block, Input3 must be used for the reset
input.
Output Test: Using this option you can select which test output signals are to be sent to
the component contacts. Short circuits between the wires can be detected and rectified by
means of this additional check. For this purpose it is necessary to configure the test out-
put signals (from the test output signals available).
StartUp Test: If selected, the test is undertaken on switching on the external components.
This test is undertaken by pressing and releasing the footswitch to carry out one com-
plete function test and to activate the output. This test is only requested on starting the
machine (on switching on the module).
Filter (ms): This parameter makes it possible to filter the signals that are received from
the external contactors. The filter can be set to between 3 and 250 ms and removes any
contact bounce. The time set for the filter affects the calculation of the total response
time of the module.
With Simultaneity: If selected, the simultaneous switching of the signals received from
the external contacts is checked.
Simultaneity (ms): This control is only available if the previous parameter has been se-
lected. Using this value you can define the maximum time (in ms) between the switching
of the two different signals that are received from the external contacts.
Enable Out Error: If selected, an error detected by the function block is signaled.
Item Description: Here you can enter a functional description for the component. The text
is displayed in the upper part of the symbol.
