CHAPTER 20
PAGE 18
PAGE DATE: 14. August 2015
MAINTENANCE MANUAL EXTRA 330LX
20-20-00 ASSEMBLY INSTRUCTION
20-20-01 General
N O T E Make appropriate logbook entry of compliance with
this Assembly Instruction after Container Shipping.
In case of the aircraft is delivered in a container it has to be
assembled on arrival.
For assembly of aircraft main components follow the in-
structions as outlined in the chapter 20-20-02.
These instructions can not replace the skill, craftsmanship
and sound technical knowledge of qualified personnel. In
case of doubt or lack of information, the manufacturer of the
respective component should be contacted for advice.
Unless otherwise specified all bolts and connections should
be torqued as listed in chapter 20-10-03. At some locations
special torque values are considered necessary. Refer to
chapter 20-10-04. The stated directions "Front" and "Rear"
are to be considered in respect of pilot`s seating direction.
20-20-02 Assembly Instruction after Container
Shipping
Complete each step of the assembly procedure in the order
shown below.
1 Check the condition of fastening of the aircraft components
in the container. Note any damage.
2 Remove the fuselage/engine assembly from the container.
Prevent the aircraft from nosing over by keeping down the
tail.
3 Weight the tail as per chapter 7.
4 Remove the aircraft components out of the container. Small
parts, hardware, spinner dome and the wheel fairings you
find in the cockpit.
