CHAPTER 32
PAGE 4
PAGE DATE: 14. August 2015
MAINTENANCE MANUAL EXTRA 330LX
32-10-01 Main Landing Gear
Removal/Installation
Refer to figure 2
1 Remove the engine cowling, the landing gear cuffs and the
bottom fuselage cover as per chapter 51.
2 Shore the aircraft as per chapter 07-20-00
3 Drain brake system.
4 Unfasten the ventilation tubing and brake lines, and discon-
nect the brake lines from the brake assembly.
5 Remove the four landing gear attachment stop nuts (1) and
the washers.
6 Remove the bottom halves of the mounting clamps (2), the
anti-abrasion strips (3) and the landing gear (4).
7 Install in reverse sequence of removal using new stop nuts.
For correctly positioning the landing gear the centering pin,
which is located at the bottom of the fuselage, is to put into
the respective sleeve at the top of the landing gear spring.
Use 3M Scotch 8671 PU tape to fasten the ventilation tubing
and brake lines. Replenish brake fluid.
32-10-02 Top Half of the Mounting Clamp
Removal/Installation
Refer to figure 2
1 Remove the main landing gear as per chapter 32-10-01.
2 Remove the stop nuts, the washers and the bolts (5).
3 Remove the top half of the mounting clamp (6).
4 Reverse procedure for installation. Apply AeroShell Grease
22C to the bolt (5) shaft and to the underside of the bolt
head and torque according to the special torque value given
in chapter 20.
