CHAPTER 24
PAGE 15
PAGE DATE: 1. March 2011
MAINTENANCE MANUAL EXTRA 330LX
24-60-02 Toggle Switch
Removal/Installation
N O T I C E Disconnect battery
1 Remove the instrument panel cover per chapter 31.
2 Disconnect the tubing from the resp. instruments.
3 Remove the instrument panel attachment screws.
4 Rotate the panel.
5 Disconnect wiring.
6 Remove the attachment nut at the front side of the instru-
ment panel.
7 Remove the switch.
8 Install in reverse sequence of removal.
24-60-03 Subminiature Pushbutton Switch
Removal/Installation
N O T I C E Disconnect battery
1 Remove the attachment nut.
2 Pull out the switch some centimeters.
3 Loosen the soldered connections.
4 Remove the switch.
5 Install in reverse sequence of removal
24-60-04 Relay
Removal/Installation
1 Disconnect battery and external power.
2 Remove the LH cuff as per chapter 51.
