CHAPTER 28
PAGE 19
PAGE DATE: 1. March 2011
MAINTENANCE MANUAL EXTRA 330LX
I M P O R T A N T Ensure LOCTITE 243 cannot get into the selector valve.
The selector valve could lock.
8 Install in reverse sequence of removal. Use LOCTITE 243
when installing the selector valve attachment bolts (2) and
the attachment screw (4).
28-20-02 Selector Valve Control Rod
Removal/Installation
(Refer to figure 8)
1 Remove the rear control rod connection bolt (11).
2 Pull the control rod (12) to the rear.
3 Remove the control rod attachment bolts (5).
4 Remove the front control rod connection bolt (7).
5 Remove the washers (8) and the spring (9), the front (6) and
the middle control rod (10).
6 Install in reverse sequence of removal.
