CHAPTER 34
PAGE 3
PAGE DATE: 1. March 2011
MAINTENANCE MANUAL EXTRA 330LX
34-00-00 GENERAL
The EXTRA 330LX is equipped with an altimeter, an air-
speed indicator and a magnetic compass in the rear cockpit.
In the front cockpit an additional airspeed indicator and
altimeter are installed.
Refer to the Equipment List of the Pilot's Operating Hand-
book for installed optional equipment.
The color markings on the instruments follow US-FAR, Part
23 recommendations.
To get the pitot and static pressure a pitot/static tube is
installed at the LH wing leading edge.
I M P O R T A N T Perform a leakage test on the pitot/static system when-
ever working on the system has been necessary.
