CHAPTER 7
PAGE 5
PAGE DATE: 1. March 2011
MAINTENANCE MANUAL EXTRA 330LX
07-20-02 Shoring the Tail
Refer to figure 3.
1 Secure the main wheels with wheel chocks.
2 Make available two approx. 2.5 feet high, approx. 1 foot wide
and approx. 3 feet long supports.
3 Cushion the supports.
W A R N I N G Do not lift the tail higher than necessary for support-
ing. The aircraft may tilt onto the nose.
N O T I C E Don't handle the elevator when lifting the tail.
4 Lift the tail some centimeters by handling carefully the hori-
zontal fins and put the cushioned supports under each side
of the horizontal stabilizer.
Figure 3 Shoring the Tail
