CHAPTER 31
PAGE 4
PAGE DATE: 14. August 2015
MAINTENANCE MANUAL EXTRA 330LX
31-10-00 INSTRUMENT AND CONTROL PANELS
31-10-01 Rear Instrument Panel
The instrument panel of the rear cockpit consists of a top
panel sheet with an instrument panel cover and a center panel
sheet. When the MVP-50 is installed generally the center
panel is enlarged (refer to Chapter 77-40-00). As an option
an additional sub-panel can be installed .
The panels and the cover are mounted on the steel frame with
AN 526 C 1032 R8 bolts.
For the standard panel arrangement of the rear cockpit refer
to Figure 1 and 2 and the adjacent charts.
N O T E The charts may be modified by the minimum equipment
requirements of individual certifying authorities.
