CHAPTER 51
PAGE 3
PAGE DATE: 1. March 2011
MAINTENANCE MANUAL EXTRA 330LX
51-00-00 GENERAL
51-00-01 Access Panel Identification
For the EXTRA 330LX all removable covers and fairings are
defined as access panels (refer to figure 1 and the adjacent
chart). If maintenance or repair is not restricted to a small
area it is advisable to remove all access panels before
beginning work or checks.
With the exception of the oil filler access door all panels are
screwed on.
The following list shows, where detailed removal/installa-
tion information for the respective parts can be found:
Part Chapter
Engine cowlings 71
Wing tip fairing 57
Fuselage covers, canopy 53
Instrument cover 31
Wheel fairings 32
N O T E Access panels partly overlap. Remove the front panels
first.
Prior to unscrewing the air inlet screen remove bottom half
of the engine cowling not to lose the attachment stopnuts and
washers.
