CHAPTER 27
PAGE 20
PAGE DATE: 17. March 2014
MAINTENANCE MANUAL EXTRA 330LX
27-20-03 Bottom Hinge Bellcranks
Removal/Installation
1 Remove the rudder per chapter 27-20-01.
2 Loosen the attachment bolts.
3 Remove the bottom hinge bellcranks.
4 Install in reverse sequence of removal.
27-20-04 Control Cable
Removal
1 Remove the respective access panels
2 Remove the cable to fuselage attachment bolts.
3 Remove the cable to rudder bellcrank attachment bolts.
4 Cut the control cables behind the front shrinking sleeves
and behind the cable to cable connection.
5 Remove the control cable parts by pulling out to the back.
Installation
Use only control cables manufactured by EXTRA Flugzeug-
produktions- und Vertriebs- GmbH. Those cables are pre-
pared for simple installation.
1 Remove the respective access panels as per chapter 51.
2 Secure the rudder (4, Figure 14) in 0°-position.
3 Mount the pre-assembled eye end of the longer control ca-
ble to the LH cable fastening (8).
4 Check that the 550 mm teflon protective hose is on the pre-
assembled control cable.
5 Thread the cable through the "S"-shaped tube at the pedal
and the pulley (7).
6 Adjust rear rudder pedals (1) in rearmost position.
