CHAPTER 33
PAGE 3
PAGE DATE: 1. March 2011
MAINTENANCE MANUAL EXTRA 330LX
33-10-00 FLIGHT COMPARTMENT
33-10-01 Low Voltage Monitor
For monitoring the generator function a low voltage monitor
is installed on the rear instrument panel (see figure 2 of
chapter 31). The indicator is dimmable and has a built-in bulb
testing device („press to test“).
N O T E When the dimmer ring is turned to the rightmost posi-
tion, the lamp is OFF.
Removal
1 BATTERY switch OFF.
2 Remove the instrument cover per chapter 31-10-03.
3 Remove the indicator by turning the dimmer ring counter-
clockwise.
4 Remove the attachment nut and washer.
5 Disconnect wiring if appropriate.
6 Remove the low voltage monitor housing.
Installation
The low voltage monitor shall be installed in such a way, that
the rightmost dimming position is at the 2 o'clock position.
This ensures an indication when the indicator is turned to the
normal position.
1 BATTERY switch OFF.
2 Connect wiring if necessary.
3 Place the low voltage monitor housing in the respective bore
hole of the instrument panel.
4 Install attachment nut and washer without tightening.
5 Install the indicator by turning the dimmer ring clockwise
to the rightmost position.
6 Turn the indicator to the 2 o'clock position.
