CHAPTER 33
PAGE 2
PAGE DATE: 14. August 2015
MAINTENANCE MANUAL EXTRA 330LX
Table of Contents
Chapter/Figure Title
33-10-00 FLIGHT COMPARTMENT . . . . . . . . . . . . . . . . . . . . 3
33-10-01 Low Voltage Monitor. . . . . . . . . . . . . . . . . . . . . . . . . . . 3
33-40-00 EXTERIOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
33-40-10 Navigation/Strobe Light System . . . . . . . . . . . . . . . . . . 5
33-40-11 Navigation/Strobe Light. . . . . . . . . . . . . . . . . . . . . . . . . 6
Figure 1 Navigation/Strobe Lights Removal/Installation . . . . . 7
33-40-12 Strobe Light Power Supply . . . . . . . . . . . . . . . . . . . . . . 8
33-40-20 LED Navigation/Strobe Light System . . . . . . . . . . . . . . 9
33-40-21 Navigation/Strobe Light. . . . . . . . . . . . . . . . . . . . . . . . . 9
Figure 2 LED Navigation/Strobe Lights Removal/Installation 10
33-40-30 Landing Light System . . . . . . . . . . . . . . . . . . . . . . . . . 11
33-40-31 Landing Light. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
33-40-32 Head Lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Figure 3 Landing Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
