CHAPTER 27
PAGE 7
PAGE DATE: 14. August 2015
MAINTENANCE MANUAL EXTRA 330LX
Figure 5 Control Rod Measurement
Refer to the following Figure 6 for identification of the
control rods.
0
1
2
6
6
7
7
8
8
Figure 6 Control Rod Identification
doRlortnoCtnemerusaeMtnemngiladnedoR
0*mm0201°0
1*mm128°0
2mm5.9812°0
6mm235°09
7mm2051°01
8mm024°09
Table 1 Control Rod Measurement & Rod End Alignment
*) Fixed rod end. Do not adjust!
