Extra 300LX - 55-40-00 RUDDER

CHAPTER 55
PAGE 11
PAGE DATE: 1. March 2011
MAINTENANCE MANUAL EXTRA 330LX
Figure 6 Layer Sequence Rudder
1 Vorgelat T35
2 1 x CCC452 45
±°
3. Reinforcement
1 x CCC452 45°
±
5 Honeycomb
4 Reinforcement
1 x CCC452 0/90°
6 1 x CCC490 ±45°
RH shell shown,
LH shell mirror-inverted
55-40-00 RUDDER
