CHAPTER 57
PAGE 7
PAGE DATE: 1. March 2011
MAINTENANCE MANUAL EXTRA 330LX
57-00-01 Wing
Removal
Reverse procedure of installation omitting step 16.
Installation
1 Remove the canopy per Chapter 53, the engine cowlings
and the main fuselage cover per Chapter 51.
2 Remove the right front canopy hinge.
3 Loosen the breather line clamps located at the engine side
of the firewall and in the main spar area, push the front part
of the breather line some centimeters to the front until it is
disconnected from the connecting hose (10, Figure 3) and
remove the breather line (5) by pulling it to the rear.
4 Fix throttle lever and control sticks in rearmost position.
5 Remove RPM-vernier-control cable per Chapter 61 and
bring cable out of the main spar area.
W A R N I N G Beware not to get jammed between wing and fuselage.
N O T I C E Ensure that areas in which the wing shall be slid are
clear of obstructions.
N O T I C E Prevent cables and pitot/static lines from damage. Keep
them at the rear of the main spar and outside of the up-
per longerons.
N O T I C E Attend to the left front canopy hinge, the throttle and
mixer cables and the heater lever, when sliding down
the wing. These parts and the wing could be damaged.
6 Slide wing down into fuselage attachment brackets (3).
7 Install LN 9037-08042 auxiliary spar attach bolts (1) from
front to rear. Use two DIN 125-M8 washers and LN 9348-
08 nuts at each side for fastening.
To Next Page
