CHAPTER 53
PAGE 8
PAGE DATE: 1. March 2011
MAINTENANCE MANUAL EXTRA 330LX
22 Sand down (using Scotch Brite Handpad Fine) the overlap-
ping part between canopy glass and canopy frame on the in-
side (Area B in figure 5).
23 Apply primer (Glasurit 934-0)(refer to chapter 51-30) and
refinish the area.
53-00-03 Main Fuselage Cover
Removal/Installation
1 Remove the canopy per chapter 53-00-01.
2 Disconnect the pitot hoses from the front instruments.
3 Remove the instrument cover per chapter 31.
4 Remove the rear canopy hinge.
5 Remove the filler neck attachment screws.
6 Remove the main fuselage cover attachment screws.
7 Remove the main fuselage cover.
8 Install in reverse sequence of removal. Perform pitot-static
system test.
