CHAPTER 4
PAGE 6
PAGE DATE: 17. March 2014
MAINTENANCE MANUAL EXTRA 330LX
04-10-00 LIFE LIMITED COMPONENTS
04-10-01 General
The replacement time of the life limited components listed
in Ch. 04-10-02 must be accomplished not later than the
specified period of operation for that component.
04-10-02 Replacement Time
Items shown here must be replaced during the regular main-
tenance periods.
Item Replace
after
fli
ht hours in service
Wing 6000 h
Aileron 6000 h
Vertical Stabilizer 6000 h
Rudder 6000 h
Horizonal Stabilizer 6000 h
Elevator 6000 h
Landing Gear Spring 6000 h
04-10-03 Service Life Limited Components
The service life of the EXTRA 330LX composite structure
as listed in section 04-10-02 has been set to 6000 flight
hours.
