CHAPTER 33
PAGE 6
PAGE DATE: 14. August 2015
MAINTENANCE MANUAL EXTRA 330LX
33-40-11 Navigation/Strobe Light
Removal/Installation
Refer to figure 1.
W A R N I N G High Voltage! Wait 5 minutes after shutting off before
starting any work on the strobe light system.
1 Disconnect the battery and wait 5 minutes.
N O T E To change a navigation LED light or glass the removal
of the Phillips screws (1) is sufficient for access.
2 Remove wing tip fairing attachment bolts (5).
3 Remove wing tip fairing (6).
4 Remove electrical wiring from cable retainer inside the wing
tip fairing.
5 Disconnect the electrical wiring.
6 Remove the lighting cover Phillips screws (1).
7 Remove the lighting cover and pull out the strobe light (2)
some centimeters.
8 Remove the lighting unit attachment bolts (3).
9 Install in reverse sequence of removal after applying Sili-
con between the wing tip fairing and the lighting unit.
