CHAPTER 28
PAGE 30
PAGE DATE: 14 August 2015
MAINTENANCE MANUAL EXTRA 330LX
3 Reinstall the float wire observing the dimensions shown in
figure 15, pay attention to a proper alignment and tighten
well the attachment bolt.
Figure 15 Float Wire Installation
4 Reinstall the lever-type tank unit as per chapter 28-40-04.
