CHAPTER 61
PAGE 9
SERVICE MANUAL EXTRA 330LX
PAGE DATE: 1. March 2011
3 Check full travel.
4 If necessary adjust rod end (1, figure 2) by the following
steps:
a Remove cotter pin, castle nut, washers and bolt from the
rod end (1) to governor control lever (2) attachment.
b Loosen the counter nut and adjust rod end (1) by turning.
Ensure thread is visible in the inspection hole when
fastening. Apply inspection lacquer on the counter nut.
c Reconnect the rod end (1) to the governor control lever (2).
PAGE DATE: 13. September 2013
