CHAPTER 71
PAGE 10
MAINTENANCE MANUAL EXTRA 330LX
PAGE DATE: 1. March 2011
3 Disconnect ignition harness.
4 Disconnect air ducting to exhaust heat exchanger at air in-
take of forward LH baffle.
5 Unscrew grommets for ignition harness and RPM Bowden
cable from their cutouts and pull out ignition harness and
RPM Bowden cable.
6 Unscrew baffle plates.
Installation
Install in reverse sequence of removal.
N O T E Minor cracks in the plating can be stopped by drilling
a hole at the end of the crack. Serious damage requires
replacement of the baffle concerned.
