CHAPTER 5
PAGE 30
PAGE DATE: 1. March 2011
MAINTENANCE MANUAL EXTRA 330LX
O 5 Inspect spades visually for general condition. Check spade support
for corrosion, cracks and deformations. Ensure proper attachment
to aileron.
O 6 Inspect ventilation holes for obstruction.
Surface general
O 7 Check paint visually for general condition (blisters etc.).
O 8 Check laminate for erosion, scratches and nicks.
Vertical Stabilizer
Leading edge
O 1 Check surface for erosion, scratches, stone nicks and impact dam-
ages.
O 2 Check left to right shell bonding for dents, cracks and delamination.
Front spar section
O 3 Check skin to spar bonding for delamination by coin tapping (refer
to chapter 20-10-05).
O 4 Detailed visual sheet metal attachment fitting for damage, corrosion
and link bolts security.
Rear spar section
O 5 Check skin to spar bonding for delamination by coin tapping .
O 6 Detailed visual inspection of rear spar web for dents, cracks and
delamination. Pay particular attention to the cut out for rudder
cantilever.
O 7 Inspect cantilever bearings for play. Check for free movement and
cleanliness.
O 8 Check steel sleeve for secure bonding to the spar.
O 9 Replace attachment bolts and stop nuts. Check for proper torque in
accordance with chapter 20-10-02.
Root and Tip
O 10 Check root rib for cracks, delamination and secure bonding to skin
and spars by coin tapping.
O 11 Inspect tip rib visually for general condition.
Inspector:
Mechanic:
Inspections
Date:
Serial No.:
1000 hours
SCHEDULED MAINTENANCE CHECKS
Significant Items Inspection
