FAAC A1000 User Manual

A1000 89 532210 04 - Rev.A
Translation of the original instructions
ENGLISH
3 Outputs O1 / O2
1. Select an input from the list:
- O1
- O2
2. Select function:
- Disabled (0)
- Gong (1)
- Error (2)
- Battery (3)
- Emergency active (4)
- Test for I1, I2, I3 and I4 (5)
- Door not closed (6)
- Door open (7)
- Door in motion (8)
- Light*(9)
- Intrusion active (10)
- Closing Safety (11)
- Closing or Opening Safety (12)
(
* ) If this function is selected, set the time:
- from 1s to 255s (Default 60s)
Default CF1 CF2 CF2 CF4 CF5
O1 6 6 6 6 --
O2 2 2 2 2 --
3. If the output has not been disabled, select the type of contact:
- Normally open (NO)
- Normally closed (NC)
Default CF1 CF2 CF2 CF4 CF5
Contact Normally closed (NC) --
4. Repeat the procedure for the other output.
3 Safety devices S1-S2
Select a SAFETY input. :
- S1
- S2
5. Select function:
SEE INPUTS LIST I1-I4
Default CF1 CF2 CF2 CF4 CF5
S1 CLOSING SAFETY --
S2 CLOSING SAFETY --
6. If the input has not been disabled, set the TEST:
Default CF1 CF2 CF2 CF4 CF5
TEST Enabled --
- Enabled
- Disabled
7. If the input has not been disabled, select the logic:
- Normally open (NO)
- Normally closed (NC)
Default CF1 CF2 CF2 CF4 CF5
Contact Normally closed (NC) --
8. Repeat the procedure for the other inputs.
4 Emergencies E1 / E2
1. Select input E1 from the list:
- E1
- E2
2. Select function:
SEE INPUTS LIST I1-I4
Default CF1 CF2 CF2 CF4 CF5
E1 Disabled --
E2 Disabled --
3. If the input is enabled, select the type of contact:
- Normally open (NO)
- Normally closed (NC)
Default CF1 CF2 CF2 CF4 CF5
Contact Normally open (NO) --
5 XFA photocells
XFA photocell inputs are disabled by default.
1. Select:
- Disabled
- 1 pair
- 2 pairs
Default CF1 CF2 CF2 CF4 CF5
XFA photocells Disabled
■
2 MOVEMENT
OK
OK
MOTION
2
PROGRAMMING
Opening
Select and modify the parameter from the list:
- 1 SPEED from 1 to 10
- 2 SLOWDOWN from 0 to 200 cm
SLOWDOWN SPEED from 1 to 3
- 3 FORCE from 1 to 10
- 4 FORCE TIME from 0.1 to 3.0s
- 5 ACCELERATION from 1 to 10
- 6 DECELERATION from 1 to 10
Default CF1 CF2 CF2 CF4 CF5
SPEED 10 8 8 5 ---
SLOWDOWN 1 1 1 1 ---
SLOWDOWN SPEED 1 1 1 1 ---
FORCE 8 8 8 8 ---
FORCE TIME 1.0 1.0 2.0 1.0 ---
ACCELERATION 8 8 5 8 ---
DECELERATION 6 6 6 4 ---
Closing
Select and modify the parameter from the list:
- 1 SPEED from 1 to 10
- 2 SLOWDOWN from 0 to 200cm
SLOWDOWN SPEED from 1 to 3
- 3 FORCE from 1 to 10
- 4 FORCE TIME from 0.1 to 3.0s
- 5 ACCELERATION from 1 to 10
- 6 DECELERATION from 1 to 10
- 7 REVERSE(*) 5 from 1 to 5
