FaroArm® Quantum
August 2017
90
Chapter 4: Probes
When the laser is operating, the Quantum Handle LED illuminate. Figure 4-5
identifies the location of the laser emission indicator.
The LED also indicates the range of the laser to the target surface. For more
information, see “Range Finder Dialog Box” on page 96.
CAUTION: VIEWING THE LASER OUTPUT WITH CERTAIN
OPTICAL INSTRUMENTS (EYE LOUPES, MAGNIFIERS, AND
MICROSCOPES, ETC.) WITHIN A DISTANCE OF 100
MM MAY POSE
AN EYE HAZARD.
WARNING: DO NOT ATTEMPT TO OPEN THE FARO LASER LINE
PROBE CASE. THERE ARE NO USER-SERVICEABLE PARTS.
Figure 4-5 Laser Emission Indicator
FARO Laser Line Probe HD
Laser power up to 18 mW at 450 nm in a diverging beam could be
accessible in the interior of the FARO Laser Line Probe.
08m80e00_FaroArm_Quantum.book Page 90 Tuesday, August 22, 2017 11:03 AM
