Chapter 4 Installation and Wiring
PAGE 4-55
⑤ 1st fastening Reject (Failure) Item
Reject Item Output format
No Reject 00
Peak torque high limit 01
Peak torque low limit 02
Final torque high limit 03
Final torque low limit 04
Final angle high limit 05
Final angle low limit 06
Differential + angle 07
Differential - angle 08
Rate 1 high limit 09
Rate 1 low limit 10
Rate 2 high limit 11
Rate 2 low limit 12
Rate 3 high limit 13
Rate 3 low limit 14
1st time high limit
15
1st time low limit
16
2nd time high limit
17
2nd time low limit
18
Rundown revolution high limit
19
Rundown revolution low limit
20
SNUG torque high limit
21
Start torque inhibit high limit
22
