● PLC Expansion Output Signals (MASTER Axis ￫ Expansion I/O)
The mapping of the output signals is programmable using the “PLC Output Layout” of the
AFC3000 User Console Software. A description of available output signals can be found below,
later in this chapter. Output signals from the Master spindle (as a group) or individual connected
spindles is available. These signals are user – configurable and maybe programmed at any
output pin / bit location.
Below is just an EXAMPLE of an output layout.
