FEC AFC3000 - Page 148

Chapter 5 I/O Expansion Unit
Page 5-17
RATE1 LO REJ. No. # (1 to 32): Rate 1 Low Limit Signal of Spindle 1-32
The signal is set “ON” if the value of rate 1 is below the fastening parameter D-No. 300 “Rate 1 Low
Limit.”
RATE2 HI REJ. No. # (1 to 32): Rate 2 High Limit Signal of Spindle 1-32
The signal is set “ON” if the value of rate 2 exceeds the fastening parameter D-No. 303 “Rate 2 High
Limit.”
RATE2 LO REJ. No. # (1 to 32): Rate 2 Low Limit Signal of Spindle 1-32
The signal is set “ON” if the value of rate 2 is below the fastening parameter D-No. 302 “Rate 2 Low
Limit.”
RATE3 HI REJ. No. # (1 to 32): Rate 3 High Limit Signal of Spindle 1-32
The signal is set “ON” if the value of rate 3 exceeds the fastening parameter D-No. 305 “Rate 3 High
Limit.”
RATE3 LO REJ. No. # (1 to 32): Rate 3 Low Limit Signal of Spindle 1-32
The signal is set “ON” if the value of rate 3 is below the fastening parameter D-No. 304 “Rate 3 Low
Limit.”
NOTE:The following output signals can be set in “PLC Output Layout” of the AFC3000 User
Console Software.
OUTPUT PORT (1 to 8): Output Signal Ports 1 to 8
These signals will output when the fastening sequence reaches a step that has a [PLC OUTPUT]
instruction inserted. Used to provide sequence operation status to external PLC’s and/or control
outputs for slide motion, lights, & buzzers, etc without the use of a PLC. (The AFC User Console
Software can set these outputs on and off in the fastening sequence)
Also, the OUTPUT PORT signals are set “OFF” under the following conditions;
 When the START signal is ON (“OFF” ￫ “ON”)
 When the REVERSE signal is ON (“OFF” ￫ “ON”)
 When the RESET signal is “ON”
 When the STOP signal is “ON”
 During a transducer CAL or Zero Level check (Self Check)
TRQ. RCV No. # (1 to 32): Torque Hold Signal of Spindle 1-32
The signal is set “ON” if the value of the operation in D-No. 315 “Torque Recovery Time” is being
performed in the fastening operation.
PAR SELECT No. #(1 to 32): Parameter No. Return Signal (Individual)
Confirms the parameter number that is being used in the fastening operation.
PEAK TQ HI REJ. No. # (1 to 32): Peak Torque High Limit Signal of Spindle 1-32
The signal is set “ON” if the value of the peak torque exceeds the fastening parameter D-No. 102
“Peak Torque High Limit.”
