Chapter 5 I/O Expansion Unit
Page 5-20
5-3-7 Timing Chart
● Basic Control Signals: Master
100msec
OFF: Contact is “Open” from the PLC
ON: Contact is “Closed” from the PLC
･ Input Signals
･ Output Signals
Fastening
Operation in
progress
Operation
