Chapter 7 Fastening Instructions
PAGE 7-15
<Three-step Fastening – Using 1
st
and 2
nd
Torque (synchronize/stops)>
<Three-step Fastening – Using 1
st
Torque and 2
nd
Angle (synchronize/stops)>
・
・・
・1
st
Torque needs to be set lower than SNUG Torque [1
st
Torque < SNUG Torque] when a
spindle synchronizes with other spindles at 1
st
Torque or when you want to improve
the accuracy of the angle judgment. (Due to spindle relaxation during synchronizing)
・
・・
・Set 1
st
Angle higher than the Final Angle High Limit and 2
nd
Torque equal to Full Scale
Torque.
・
・・
・1
st
Torque needs to be set lower than SNUG Torque [1
st
Torque < SNUG Torque] when a
spindle synchronizes with other spindles at 1
st
Torque or when you want to improve
the accuracy of the angle judgment. (Due to spindle relaxation during synchronizing)
・
・・
・Set 1
st
Angle and 2
nd
Angle higher than the Final Angle High Limit.
Torque
Angle/Time
Snug Torque
1
st
Time
2
nd
Time
Standard Angle
Ramp Down Start Torque
1
st
Torque
2
nd
Torque
Torque
Angle/Time
Snug Torque
1
st
Time
2
nd
Time
Standard Angle
Ramp Down Start Torque
1
st
Torque
2
nd
Angle
